AUTOXFMR 347120/277 150VA C&C PHILIPS 509604
MFR Part #: 509604
SKU #: 1117278
Brand: Signify | Advance
UPC: 781087046869
Advance 509604 Core and Coil Step Down Auto Transformer With HID Ballast, 347 V AC Input, 120/277 VAC Output, 75 W, 0.92 A
This product may be subject to ecological fees.
High Bay Retail, Manufacturing, Gymnasiums, Warehouse, Parking Structures and Outdoor Applications
ANSI M137-M152 | BAA Compliant | CSA Certified | UL File No E65627 AD 180
Product Details
Attributes
Features
Resources
Advance Step Down Auto Transformer, Core and Coil, 347 V AC Input, 120/277 VAC Output, 75 W, 0.92 A, 60 Hz, 180 deg C Class H, 2.6 in L x 3.9 in W x 2.2 in H
Amperage Rating:.92 A
Dimensions:2.6 in L x 3.9 in W x 2.2 in H
Frequency Rating:60 Hz
Input Voltage:347 V AC
Insulation:180 deg C Class H
Output Voltage:120/277 V AC
Type:Core and Coil
Wattage:75 W
- Used to connect a lower voltage device to a higher voltage source
- Convenient J-Box cover with thermal protector available for some transformers
- Linear transformer design operates cooler than a ballast
Product Details
Advance Step Down Auto Transformer, Core and Coil, 347 V AC Input, 120/277 VAC Output, 75 W, 0.92 A, 60 Hz, 180 deg C Class H, 2.6 in L x 3.9 in W x 2.2 in H
Attributes
Amperage Rating: .92 A
Dimensions: 2.6 in L x 3.9 in W x 2.2 in H
Frequency Rating: 60 Hz
Input Voltage: 347 V AC
Insulation: 180 deg C Class H
Output Voltage: 120/277 V AC
Type: Core and Coil
Wattage: 75 W
Features
- Used to connect a lower voltage device to a higher voltage source
- Convenient J-Box cover with thermal protector available for some transformers
- Linear transformer design operates cooler than a ballast
