ISOXFMR 27711.8V 75VA C&C PHILIPS 493387
MFR Part #: 493387
SKU #: 1117074
Brand: Signify | Advance
UPC: 781087092774
Advance 493387 Core and Coil Step Down Auto Transformer With HID Ballast, 277 V AC Input, 11.8 VDC Output, 75 W, 0.3 A
This product may be subject to ecological fees.
High Bay Retail, Manufacturing, Gymnasiums, Warehouse, Parking Structures and Outdoor Applications
UL File No. E65627 AD 180 | CSA Certified | ANSI M137-M152
Product Details
Attributes
Features
Resources
Advance Step Down Auto Transformer, Core and Coil, 277 V AC Input, 11.8 VDC Output, 75 W Wattage, 0.3 A, 60 Hz Frequency, 180 deg C Class H Insulation, 2.6 in L x 2.8 in W x 2.2 in H Dimensions
Amperage Rating:.3 A
Dimensions:2.6 in L x 2.8 in W x 2.2 in H
Frequency Rating:60 Hz
Input Voltage:277 V AC
Insulation:180 deg C Class H
Output Voltage:11.8 V DC
Type:Core and Coil
Wattage:75 W
- Used to connect a lower voltage device to a higher voltage source
- Convenient J-Box cover with thermal protector available for some transformers
- Linear transformer design operates cooler than a ballast
Product Details
Advance Step Down Auto Transformer, Core and Coil, 277 V AC Input, 11.8 VDC Output, 75 W Wattage, 0.3 A, 60 Hz Frequency, 180 deg C Class H Insulation, 2.6 in L x 2.8 in W x 2.2 in H Dimensions
Attributes
Amperage Rating: .3 A
Dimensions: 2.6 in L x 2.8 in W x 2.2 in H
Frequency Rating: 60 Hz
Input Voltage: 277 V AC
Insulation: 180 deg C Class H
Output Voltage: 11.8 V DC
Type: Core and Coil
Wattage: 75 W
Features
- Used to connect a lower voltage device to a higher voltage source
- Convenient J-Box cover with thermal protector available for some transformers
- Linear transformer design operates cooler than a ballast
