B&G 110196 3/4 BOILER FEED B7 - 12
MFR Part #: 110196
SKU #: 0520267
Brand: Bell & Gossett
UPC: 683328101965
Bell & Gossett B7-12 Series 110196 Pressure Reducing Valve, 3/4 in Nominal, NPT, 5.5 to 6 gpm at 125 psi, 10 to 25 psi
For potable water systems
Product Details
Attributes
Features
Resources
Bell & Gossett Pressure Reducing Valve, B7-12 Series, 3/4 in Nominal, NPT Connection, 10 to 25 psi, 5.5 to 6 gpm at 125 psi Flow Rate, Brass Body, Brass Seat, Brass/EPDM Stem, 225 deg F, 3 in L x 5-1/32 in H
Body Material:Brass
Dimensions:3 in L x 5-1/32 in H
End Style:NPT
Flow Rate:5.5 to 6 gpm at 125 psi
Nominal Size:3/4 in
Pressure Rating:10 to 25 psi
Seat Material:Brass
Series:B7-12 Series
Stem Material:Brass/EPDM
Temperature Rating:225 deg F
- Fast fill feature reduces start-up time and labor
- Low inlet pressure check valve help prevent loss of system pressure if the supply water drops below system pressure
- Convenient cleanable strainer is designed to prevent dirt and sediment from entering the system
- Brass body construction is highly-resistant to corrosion-ideal for water systems
- Reducing valves protect heating and plumbing systems against excessive line pressures
- Equipped with built-in-strainer and low inlet pressure check valve
- They are factory set at specified limits although adjustment is easily made
- Construction-cast brass body, with special insert diaphragm, EPDM check valve, brass seat, brass with EPDM insert stem, brass valve plate, stainer and strainer nut wetted parts and steel non-wetted parts
Product Details
Bell & Gossett Pressure Reducing Valve, B7-12 Series, 3/4 in Nominal, NPT Connection, 10 to 25 psi, 5.5 to 6 gpm at 125 psi Flow Rate, Brass Body, Brass Seat, Brass/EPDM Stem, 225 deg F, 3 in L x 5-1/32 in H
Attributes
Body Material: Brass
Dimensions: 3 in L x 5-1/32 in H
End Style: NPT
Flow Rate: 5.5 to 6 gpm at 125 psi
Nominal Size: 3/4 in
Pressure Rating: 10 to 25 psi
Seat Material: Brass
Series: B7-12 Series
Stem Material: Brass/EPDM
Temperature Rating: 225 deg F
Features
- Fast fill feature reduces start-up time and labor
- Low inlet pressure check valve help prevent loss of system pressure if the supply water drops below system pressure
- Convenient cleanable strainer is designed to prevent dirt and sediment from entering the system
- Brass body construction is highly-resistant to corrosion-ideal for water systems
- Reducing valves protect heating and plumbing systems against excessive line pressures
- Equipped with built-in-strainer and low inlet pressure check valve
- They are factory set at specified limits although adjustment is easily made
- Construction-cast brass body, with special insert diaphragm, EPDM check valve, brass seat, brass with EPDM insert stem, brass valve plate, stainer and strainer nut wetted parts and steel non-wetted parts
