CARLO GAVAZZI SPD12101 Image 1

CARLO GAVAZZI SPD12101 POWER SUPPLY 12VDC .83AMP 10WATT

MFR Part #: SPD12101
SKU #: 1123633
Brand: Carlo Gavazzi
UPC: 8032970000000
Carlo Gavazzi SPD12101 Switching Power Supply, 264 VAC Input, 12 VDC Output, 0.84 A Output, LED Indicator, Plastic
cUL Listed | TUV/CE Marked | UL Listed

Carlo Gavazzi Switching Power Supply, 264 VAC Input, 12 VDC Output, +/-1 % Output Voltage Accuracy, 0.84 A Output, 150 ms Output Voltage Falling Time, +/-2 % Load Regulation, +/-1 % Line Regulation, 2 ms Recovery Time, -20 to 71 deg C Operating, Short Circuit Protection Type, LED Indicator, Plastic, 90 mm H x 22.5 mm W x 114 mm D

The Switching power supplies SPD Series are specially designed to be used in all automation application where the installation is on a DIN rail and compact dimensions and performance are a must.

Product Details

Carlo Gavazzi Switching Power Supply, 264 VAC Input, 12 VDC Output, +/-1 % Output Voltage Accuracy, 0.84 A Output, 150 ms Output Voltage Falling Time, +/-2 % Load Regulation, +/-1 % Line Regulation, 2 ms Recovery Time, -20 to 71 deg C Operating, Short Circuit Protection Type, LED Indicator, Plastic, 90 mm H x 22.5 mm W x 114 mm D

The Switching power supplies SPD Series are specially designed to be used in all automation application where the installation is on a DIN rail and compact dimensions and performance are a must.

Attributes

Dimensions: 90 mm H x 22.5 mm W x 114 mm D
Indicator Type: LED
Input Voltage: 264 VAC
Line Regulation: +/-1 %
Load Regulation: +/-2 %
Material: Plastic
Operating Temperature: -20 to 71 deg C
Output Current: .84 A
Output Voltage: 12 VDC
Output Voltage Accuracy: +/-1 %
Output Voltage Falling Time: 150 ms
Protection Type: Short Circuit
Recovery Time: 2 ms

Features

  • Universal AC input full range
  • Installation on DIN rail 7.5 or 15 mm
  • Short-circuit protection
  • Overload protection
  • High-efficiency
  • LED indicator for DC power on
  • LED indicator for DC low
  • Power ok output
  • Internal input filter

Resources

Specification Sheet
