GOODMAN GPH1660H41 5 TON PKGD 16 SEER HP 7MM
MFR Part #: GPH1660H41
SKU #: 1219440
Brand: Goodman®
UPC: 978903
Goodman® GPH16H Series GPH1660H41 Package Heat Pump, 5 ton Nominal, 54500 Btu/hr Heating Btu, 208 - 230 VAC
AHRI Certified, C/US ETL Intertek Listed, BBB accredited, ISO 9001, ISO 14001 Certified
Product Details
Attributes
Features
Goodman® Package Heat Pump, Series: GPH16H, 5 ton Nominal, 57500 Btu/hr Cooling Cooling BTU Rating, 54500 Btu/hr Heating Heating BTU Rating, 208 - 230 VAC, 40 A, 60 Hz, 1 -Phase, Scroll Compressor, 16 SEER, Configuration: Horizontal, R-410A Refrigerant, 2 -Stage, 60 A Fuse, 80 dBA, Heavy Gauge Steel, Galvanized, Powder-Painted, Gray, 66 in W x 38-3/4 in H x 34 in D
Amperage Rating:
40 A
Color:
Gray
Compressor Type:
Scroll
Configuration:
Horizontal
Cooling BTU Rating:
57500 Btu/hr Cooling
Dimensions:
66 in W x 38-3/4 in H x 34 in D
Finish:
Galvanized, Powder-Painted
Frequency Rating:
60 Hz
Fuse Rating:
60 A
Heating BTU Rating:
54500 Btu/hr Heating
Material:
Heavy Gauge Steel
Nominal Capacity:
5 ton
Number of Stages:
2
Phase:
1
Refrigerant Type:
R-410A
SEER Rating:
16
Series:
GPH16H
Sound Level:
80 dBA
Voltage Rating:
208 - 230 VAC
- Energy-efficient compressor
- Two-speed ECM indoor blower motor
- All aluminum evaporator coils
- Copper tube/aluminum fin coils
- Totally enclosed permanently lubricated condenser fan motor
- Fully charged system
- Electric heat kit available as a field installed accessory
- Fully insulated blower compartment with convenient access panels
- Cabinet air leakage less than 2% at 1 in H2O when tested in accordance with ASHRAE standard 193
- Cabinet air leakage less than 1.4% at 1/2 in H2O when tested in accordance with ASHRAE standard 193
- Louvered condenser coil protection
- 10 years limited parts warranty
Product Details
Goodman® Package Heat Pump, Series: GPH16H, 5 ton Nominal, 57500 Btu/hr Cooling Cooling BTU Rating, 54500 Btu/hr Heating Heating BTU Rating, 208 - 230 VAC, 40 A, 60 Hz, 1 -Phase, Scroll Compressor, 16 SEER, Configuration: Horizontal, R-410A Refrigerant, 2 -Stage, 60 A Fuse, 80 dBA, Heavy Gauge Steel, Galvanized, Powder-Painted, Gray, 66 in W x 38-3/4 in H x 34 in D
Attributes
Amperage Rating: 40 A
Color: Gray
Compressor Type: Scroll
Configuration: Horizontal
Cooling BTU Rating: 57500 Btu/hr Cooling
Dimensions: 66 in W x 38-3/4 in H x 34 in D
Finish: Galvanized, Powder-Painted
Frequency Rating: 60 Hz
Fuse Rating: 60 A
Heating BTU Rating: 54500 Btu/hr Heating
Material: Heavy Gauge Steel
Nominal Capacity: 5 ton
Number of Stages: 2
Phase: 1
Refrigerant Type: R-410A
SEER Rating: 16
Series: GPH16H
Sound Level: 80 dBA
Voltage Rating: 208 - 230 VAC
Features
- Energy-efficient compressor
- Two-speed ECM indoor blower motor
- All aluminum evaporator coils
- Copper tube/aluminum fin coils
- Totally enclosed permanently lubricated condenser fan motor
- Fully charged system
- Electric heat kit available as a field installed accessory
- Fully insulated blower compartment with convenient access panels
- Cabinet air leakage less than 2% at 1 in H2O when tested in accordance with ASHRAE standard 193
- Cabinet air leakage less than 1.4% at 1/2 in H2O when tested in accordance with ASHRAE standard 193
- Louvered condenser coil protection
- 10 years limited parts warranty
