JW 100279401 DV50N 300 50USG NATURAL GAS DIRECT VENTED WATER HEATER
Product Details
Attributes
Features
Resources
John Wood® Propane Gas Water Heater, 300 Series, 50 gal Capacity, 40000 Btu/hr, 91 gph First Hour Delivery, 0.62 Energy Factor, 43 gph Recovery Rate, Direct Vent, Natural Gas Fuel, Piezo-Electric Ignition, 22 in Dia x 58-7/8 in H x 29 in D, 7700 ft Altitude
A proven performer with 10 year of laboratory testing and field trials including nine winters in the extreme cold, the John wood direct vent operates quietly with no need for an electric fan or external power supply. The balanced flue design with a side wall vent termination allows installation in locations without a chimney. The sealed combustion chamber and coaxial vent uses fresh air taken from outside rather than pre-heated air from within the home.
- ProLine® models are residential water heaters with commercial-grade quality
- Thermopile system provides a robust pilot to withstand environmental conditions such as down drafts
- Suitable for closet installations due to direct vent design not requiring an external power supply or chimney
- Sealed combustion chamber design, eliminating the need for a flammable vapor sensor
- 50 USG high input model available for combination applications
- 3/4 in side taps available on 50 USG high input model for combination applications
- LED indicator gives visual confirmation that the pilot is on and provides diagnostics and troubleshooting information
- Glass lining provides superior protection against tank corrosion
- Top-mounted heavy-duty anode rod for added tank protection
- Maintenance is simple with an easy-to access combustion chamber and conveniently located drain valve
- Easy temperature adjustments
- 90 in coaxial vent supplied with water heater
- Factory installed plastic lined nipples with heat traps
- Automatic gas control
- CFC-free foam insulation
- Piezoelectric ignitor allows for push button pilot lighting
Product Details
John Wood® Propane Gas Water Heater, 300 Series, 50 gal Capacity, 40000 Btu/hr, 91 gph First Hour Delivery, 0.62 Energy Factor, 43 gph Recovery Rate, Direct Vent, Natural Gas Fuel, Piezo-Electric Ignition, 22 in Dia x 58-7/8 in H x 29 in D, 7700 ft Altitude
A proven performer with 10 year of laboratory testing and field trials including nine winters in the extreme cold, the John wood direct vent operates quietly with no need for an electric fan or external power supply. The balanced flue design with a side wall vent termination allows installation in locations without a chimney. The sealed combustion chamber and coaxial vent uses fresh air taken from outside rather than pre-heated air from within the home.
Attributes
Features
- ProLine® models are residential water heaters with commercial-grade quality
- Thermopile system provides a robust pilot to withstand environmental conditions such as down drafts
- Suitable for closet installations due to direct vent design not requiring an external power supply or chimney
- Sealed combustion chamber design, eliminating the need for a flammable vapor sensor
- 50 USG high input model available for combination applications
- 3/4 in side taps available on 50 USG high input model for combination applications
- LED indicator gives visual confirmation that the pilot is on and provides diagnostics and troubleshooting information
- Glass lining provides superior protection against tank corrosion
- Top-mounted heavy-duty anode rod for added tank protection
- Maintenance is simple with an easy-to access combustion chamber and conveniently located drain valve
- Easy temperature adjustments
- 90 in coaxial vent supplied with water heater
- Factory installed plastic lined nipples with heat traps
- Automatic gas control
- CFC-free foam insulation
- Piezoelectric ignitor allows for push button pilot lighting
