CSC FL01-30W Image 1

CSC FL01-30W FLD LGHT 30W 120-277V DLC 5K 3718LM 90X120

MFR Part #: FL01-30W
SKU #: 1202602
Brand: CSC LED
UPC: 845599010074
CSC LED Daymaker Series FL01-30W Flood Light, 120-277 V, 30 W, LED Lamp, 3718 Lumens, 5000 K, Aluminum
10 Year
This product may be subject to ecological fees.
Parking Lot, Construction Sites, Storage and Rail Yards, Industrial Location, Marinas, Billboard/Sign Illumination
cULus E352127 Listed | DLC Listed

CSC LED Flood Light, Daymaker Series, 120-277 V, 30 W Wattage, Rectangular Shape, LED Lamp, Polycarbonate Lens, 3718 Lumens, 50000 hr Average Life, 82.5 CRI, 5000 K, 120 x 90 deg Beam Angle, 86.9 mm Maximum Overall Length, Non-Dimmable, 0.92 Power Factor, Aluminum, Matte Black, Finish: Powder-Coated, -40 to 55 deg C, 86.9 mm L x 179.7 mm W x 167.4 mm H

Product Details

CSC LED Flood Light, Daymaker Series, 120-277 V, 30 W Wattage, Rectangular Shape, LED Lamp, Polycarbonate Lens, 3718 Lumens, 50000 hr Average Life, 82.5 CRI, 5000 K, 120 x 90 deg Beam Angle, 86.9 mm Maximum Overall Length, Non-Dimmable, 0.92 Power Factor, Aluminum, Matte Black, Finish: Powder-Coated, -40 to 55 deg C, 86.9 mm L x 179.7 mm W x 167.4 mm H

Attributes

Average Life: 50000 hr
Color Rendering Index (CRI): 82.5
Color Temperature: 5000 K
Dimensions: 86.9 mm L x 179.7 mm W x 167.4 mm H
Lamp Type: LED
Lumens: 3718 Lumens
Series: Daymaker Series
Voltage Rating: 120-277 V
Beam Angle: 120 x 90 deg
Color: Matte Black
Dimmable/Non-Dimmable: Non-Dimmable
Finish: Powder-Coated
Lens Material: Polycarbonate
Material: Aluminum
Maximum Overall Length: 86.9 mm
Power Factor: .92
Shape: Rectangular
Temperature Rating: -40 to 55 deg C
Wattage: 30 W

Features

  • Lumiled chips
  • Large thermal dissipation area
  • High grade polycarbonate optics will never yellow
  • Versatile yoke

Resources

Specification Sheet
