DEWALT 2700SD Image 1

DEWALT 2700SD-PWR TAPPER+ HWH 3/16 X 1 1/4

MFR Part #: 2700SD
SKU #: 1181869
Brand: DeWALT®
UPC: 75352820620
DeWALT® 2700SD Self-Threading Concrete Screw Anchor, 3/16 in Dia, 1-1/4 in OAL, Hex Washer Head Drive, Case Hardened Carbon Steel, 1-3/4 in D Min Embedment
Window Installations, Storm Shutters, Interior Hand Rails, Interior Lighting Fixtures, Metal door frames, Thresholds, Joint flashing and Screened Enclosures
ICC-ES | UL Listing | FM Approvals | GSA/CID | ANSI/NSF 61 | ACI 355.2 | ICC-ES AC193

DeWALT® Concrete Screw Anchor, Self-Threading, Series: Tapper+®, 3/16 in Diameter, 1-1/4 in Overall Length, Hex Washer Head Drive, Case Hardened Carbon Steel, 1-3/4 in Minimum Embedment Depth, 5/32 in Drill, Blue Perma-Seal Coated, Applicable Materials: Concrete/Lightweight Concrete/Grouted Concrete/Masonry/Hollow Concrete Masonry (CMU)/Solid Brick Masonry/Wood, High/Low Thread, 7/64 in H Head, 985 lb Shear Strength, 1760 lb Tensile Strength

Product Details

DeWALT® Concrete Screw Anchor, Self-Threading, Series: Tapper+®, 3/16 in Diameter, 1-1/4 in Overall Length, Hex Washer Head Drive, Case Hardened Carbon Steel, 1-3/4 in Minimum Embedment Depth, 5/32 in Drill, Blue Perma-Seal Coated, Applicable Materials: Concrete/Lightweight Concrete/Grouted Concrete/Masonry/Hollow Concrete Masonry (CMU)/Solid Brick Masonry/Wood, High/Low Thread, 7/64 in H Head, 985 lb Shear Strength, 1760 lb Tensile Strength

Attributes

Clearance Items: Clearance
Color: Blue
Country Of Origin: Taiwan
Diameter: 3/16 in
Head Type: Hex Washer
Length: 1-1/4 in
Material: Carbon Steel
Overall Length: 1-1/4 in

Features

  • The Tapper+ fastening system is a complete family of screw anchors for light to medium duty applications in concrete, masonry block, brick, and wood base materials
  • The Tapper+ is fast and easy to install and provides a neat, finished appearance
  • The Tapper+ screw anchor is engineered with matched tolerance drill bits and installation tools designed to meet the needs of the user and also provide optimum performance
  • The Tapper+ features a gimlet point for self-drilling into wood base materials without pre-drilling
  • High-low thread design for greater stability and grip
  • Does not exert expansion forces
  • No hole spotting required
  • Good corrosion protection with Perma-Seal coating
  • Gimlet point
