WESTINGHOUSE BAB3040H Image 1

EATON BAB3040H 3 POLE 40 AMP BOLT-IN BREAKER

MFR Part #: BAB3040H
SKU #: 0711470
Brand: EATON
UPC: 786679303405
EATON QuickLag® BAB3040H Type BAB Miniature Circuit Breaker, 240 VAC, 40 A, 10 kA Interrupt, 3 Poles, Non-Interchangeable/Thermal Magnetic Trip
Datacentres, IT Space, CI and Hyper Converged, Generation - Conventional Energy, Renewable Energy, Alternative Energy, Marine Vessels and Equipment, Residential Buildings and Facilities, Circuit Protection and Industrial Applications
CSA Certified | HACR Rated | UL 489

EATON QuickLag® Miniature Circuit Breaker, Type BAB, 240 VAC, 40 A, 10 kA Interrupt, Non-Interchangeable/Thermal Magnetic Trip, 3 Pole, 3 ph, 14 to 4 AWG Wire, Bolt-On Mount, 3.8 x 3.2 x 4.7 in

Eaton’s bolt-on miniature circuit breakers (Quicklag) provide superior protection in panelboards, and offer easy installation. They are also switching duty rated for 120 VAC fluorescent light applications, and UL 489 listed. All products 15–100A are HACR rated. Select from one-, two-, or three-pole designs.

Product Details

EATON QuickLag® Miniature Circuit Breaker, Type BAB, 240 VAC, 40 A, 10 kA Interrupt, Non-Interchangeable/Thermal Magnetic Trip, 3 Pole, 3 ph, 14 to 4 AWG Wire, Bolt-On Mount, 3.8 x 3.2 x 4.7 in

Eaton’s bolt-on miniature circuit breakers (Quicklag) provide superior protection in panelboards, and offer easy installation. They are also switching duty rated for 120 VAC fluorescent light applications, and UL 489 listed. All products 15–100A are HACR rated. Select from one-, two-, or three-pole designs.

Attributes

Amperage Rating: 40 A
Country Of Origin: Dominican Republic
Number of Poles: 3
Dimensions: 3.8 x 3.2 x 4.7 in
Interrupt Rating: 10 kA
Mounting Type: Bolt-On
Phase: 3
Trip Type: Non-Interchangeable/Thermal Magnetic
Type: Type BAB
Voltage Rating: 240 VAC
Wire Size: 14 to 4 AWG

Features

  • Flexible power feed connection
  • Field mountable accessories make installations and on-site custom configuration easy

Resources

Owners/User Manual
Specification Sheet
