WF8 LED 30K40K50K 90CRI MW M6 LITHONIA 264T5F
MFR Part #: WF8 LED 30K40K50K 90CRI MW M6
SKU #: 1224619
Brand: Acuity Brands | Lithonia Lighting®
UPC: 191848254653
Please note this item is discontinued (order fulfillment will depend on stock availability): Lithonia Lighting® Wafer™ WF8 LED 30K40K50K 90CRI MW M6 Dimmable Square Wafer Thin Recessed Downlight, Static LED Lamp, 8 in Ceiling Opening, 120 VAC, Die Cast Aluminum Housing
5 years Limited
Lamp
Hospitality, Multifamily , Commercial and Residential Applications
ENERGY STAR Certified | CSA Certified | UL Listed for Wet Location | FCC Title 47 CFR, Part 15 | Class B | California Title 24 Compliant | ASTM E283-2004
Product Details
Attributes
Features
Resources
Lithonia Lighting® Wafer™ Recessed Downlight, Dimmable Square Wafer Thin, Series: WF8, 120 VAC, 0.17 A, Edge-Lit Lighting Technology, Static LED Lamp, 20 W Lamp, 82.8/94.4/88.3 Lumens/W Light Output, 8 in Ceiling Opening, Warm White/Cool White/Daylight Light, 3000/4000/5000 K Color Temperature, 90 CRI, Polycarbonate Lens, 1690/1850/1820 Lumens, Ceiling Mounting, Die Cast Aluminum Housing Material, 2 in L x 3 in W x 4 in H Dimensions
Clearance Items:
Clearance
Country Of Origin:
China
Amperage Rating:
.17 A
Ceiling Opening:
8 in
Color Rendering Index (CRI):
90
Color Temperature:
3000/4000/5000 K
Dimensions:
2 in L x 3 in W x 4 in H
Housing Material:
Die Cast Aluminum
Lamp Type:
Static LED
Lamp Wattage:
20 W
Lens Type:
Polycarbonate
Light Color:
Warm White/Cool White/Daylight
Light Output:
82.8/94.4/88.3 Lumens/W
Lighting Technology:
Edge-Lit
Lumens:
1690/1850/1820 Lumens
Mounting Type:
Ceiling
Series:
WF8
Type:
Dimmable Square Wafer Thin
Voltage Rating:
120 VAC
- The 8 in Wafer™ LED downlight with switchable white provides high quality light output and efficiency featuring a switch for easy color temperature adjustment while eliminating the need for recessed housings
- The innovative, slim design allows for easy retrofit, remodel or new construction installation from below the ceiling
- Durable, powder coat paint prevents rust
- FT6 plenum rated cable connector to connect from module to remote driver box
- IC rated driver with convenience and value of two remote selectable color temperature options, each with a setting choice to chose either 2700 K, 3000 K and 3500 K or 3000 K, 4000 K and 5000 K using the switch
- Isolated driver integrated inside steel remote box with (4) 7/8 in knockouts with slots for pryout
- Suitable for pulling wires with the 12 cu-in wiring compartment to accommodate up to (6) 14 ga insulated conductors, making the Wafer™ LED downlights much easier to wire in 2in/2out (plus ground) daisy chain applications and contractor friendly
- Ideal for shallow ceiling plenum, no housing required
- Steel spring clip for easy installation
- 8 in cut out template is provided to ensure the correct size hole cut into ceiling for proper installation of the trim
- Edge-lit LED technology uses light guided plate to distribute light
- Polycarbonate lens provides even illumination throughout the space
Product Details
Lithonia Lighting® Wafer™ Recessed Downlight, Dimmable Square Wafer Thin, Series: WF8, 120 VAC, 0.17 A, Edge-Lit Lighting Technology, Static LED Lamp, 20 W Lamp, 82.8/94.4/88.3 Lumens/W Light Output, 8 in Ceiling Opening, Warm White/Cool White/Daylight Light, 3000/4000/5000 K Color Temperature, 90 CRI, Polycarbonate Lens, 1690/1850/1820 Lumens, Ceiling Mounting, Die Cast Aluminum Housing Material, 2 in L x 3 in W x 4 in H Dimensions
Attributes
Clearance Items: Clearance
Country Of Origin: China
Amperage Rating: .17 A
Ceiling Opening: 8 in
Color Rendering Index (CRI): 90
Color Temperature: 3000/4000/5000 K
Dimensions: 2 in L x 3 in W x 4 in H
Housing Material: Die Cast Aluminum
Lamp Type: Static LED
Lamp Wattage: 20 W
Lens Type: Polycarbonate
Light Color: Warm White/Cool White/Daylight
Light Output: 82.8/94.4/88.3 Lumens/W
Lighting Technology: Edge-Lit
Lumens: 1690/1850/1820 Lumens
Mounting Type: Ceiling
Series: WF8
Type: Dimmable Square Wafer Thin
Voltage Rating: 120 VAC
Features
- The 8 in Wafer™ LED downlight with switchable white provides high quality light output and efficiency featuring a switch for easy color temperature adjustment while eliminating the need for recessed housings
- The innovative, slim design allows for easy retrofit, remodel or new construction installation from below the ceiling
- Durable, powder coat paint prevents rust
- FT6 plenum rated cable connector to connect from module to remote driver box
- IC rated driver with convenience and value of two remote selectable color temperature options, each with a setting choice to chose either 2700 K, 3000 K and 3500 K or 3000 K, 4000 K and 5000 K using the switch
- Isolated driver integrated inside steel remote box with (4) 7/8 in knockouts with slots for pryout
- Suitable for pulling wires with the 12 cu-in wiring compartment to accommodate up to (6) 14 ga insulated conductors, making the Wafer™ LED downlights much easier to wire in 2in/2out (plus ground) daisy chain applications and contractor friendly
- Ideal for shallow ceiling plenum, no housing required
- Steel spring clip for easy installation
- 8 in cut out template is provided to ensure the correct size hole cut into ceiling for proper installation of the trim
- Edge-lit LED technology uses light guided plate to distribute light
- Polycarbonate lens provides even illumination throughout the space
