ABB 58926BE Image 1

ABB 58926BE COPPER TIN PLATED 1-HOLE LUG LONG BARREL 900 5/8B YELLOW

MFR Part #: 58926BE
SKU #: 1272513
Brand: ABB
UPC: 786210819464
Color-Keyed® 58926BE 1-Hole Compression Connector Lug, 900 kcmil Copper Conductor, Die Code: 115, 5/8 in Stud, Copper
For providing a high degree of reliability in electrical wiring
CSA C22.2 File No. 04 | CSA C22.2 File No. 65 | UL 467 | UL 486A | UL File No. E9809

Color-Keyed® Compression Connector Lug, 1-Hole, Series: 58900, Copper Conductor, 900 kcmil Conductor, Die Code: 115, 600 V to 35 kV, 5/8 in Stud, Straight Tongue, 1.58 in L x 2.17 in W x 0.31 in THK Tongue, 5.23 in Overall Length, Blind End/Long Barrel, 1-1/2 in Dia Barrel, 0.656 in Mounting Hole, Copper, Yellow

The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by Thomas & Betts. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.

Product Details

Color-Keyed® Compression Connector Lug, 1-Hole, Series: 58900, Copper Conductor, 900 kcmil Conductor, Die Code: 115, 600 V to 35 kV, 5/8 in Stud, Straight Tongue, 1.58 in L x 2.17 in W x 0.31 in THK Tongue, 5.23 in Overall Length, Blind End/Long Barrel, 1-1/2 in Dia Barrel, 0.656 in Mounting Hole, Copper, Yellow

The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by Thomas & Betts. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.

Attributes

Barrel Size: 1-1/2 in Dia
Barrel Type: Blind End/Long
Color: Yellow
Conductor Size: 900 kcmil
Conductor Type: Copper
Country Of Origin: Mexico
Die Code: 115
Material: Copper
Mounting Hole Size: .656 in
Overall Length: 5.23 in
Series: 58900
Stud Size: 5/8 in
Tongue Size: 1.58 in L x 2.17 in W x 0.31 in THK
Tongue Type: Straight
Type: 1-Hole
Voltage Rating: 600 V to 35 kV

Features

  • Connectors have colored bands or colored dots that correspond to color markings on the dies
  • Color-Keyed® connectors are banded by colored stripes or engraving to indicate location of die on connector for compression
  • Connection by compression
  • High quality connection at a low installed cost
  • High conductivity wrought copper construction
