PHILIPS 177048 Image 1

LOW PRESS SOD BALLAST 90W L72 QUAD C&C PHILIPS 177048

MFR Part #: 177048
SKU #: 1116851
Brand: Signify | Advance
UPC: 781087120019
Advance 177048 Core/Coil Magnetic HX-HPF HID Ballast, 90 W, 120/208/240/277 V AC, Probe, 1 Ballast Factor
This product may be subject to ecological fees.
Outdoor Applications
RoHS Compliant | UL Recognized | CSA Certified | UL Listed

Advance HID Ballast, Core/Coil Magnetic HX-HPF, 90 W Lamp, 125 W, 120/208/240/277 V AC, 0.5/0.53/0.6/1.06 A, 60 Hz, Probe Start, -20 deg F Minimum Starting, Power Factor: 0.9, Dimmable: No, 1 Lamp, Thermal Protection: Class P, Ballast Factor: 1, ANSI L72 Ballast Grade, 4-3/4 in L x 3-1/4 in W x 4-1/4 in H

Product Details

Advance HID Ballast, Core/Coil Magnetic HX-HPF, 90 W Lamp, 125 W, 120/208/240/277 V AC, 0.5/0.53/0.6/1.06 A, 60 Hz, Probe Start, -20 deg F Minimum Starting, Power Factor: 0.9, Dimmable: No, 1 Lamp, Thermal Protection: Class P, Ballast Factor: 1, ANSI L72 Ballast Grade, 4-3/4 in L x 3-1/4 in W x 4-1/4 in H

Attributes

Amperage Rating: 0.5/0.53/0.6/1.06 A
Ballast Factor: 1
Ballast Grade: ANSI L72
Dimensions: 4-3/4 in L x 3-1/4 in W x 4-1/4 in H
Dimmable: No
Frequency Rating: 60 Hz
Lamp Wattage: 90 W
Minimum Starting Temperature: -20 deg F
Number of Lamps: 1
Power Factor: .9
Start Type: Probe
Thermal Protection: Class P
Type: Core/Coil Magnetic HX-HPF
Voltage Rating: 120/208/240/277 V AC
Wattage: 125 W

Features

  • The basic ballast is the open core and coil which is most often used as a component within a lighting luminaire
  • The core and coil also forms the nucleus of Philips Advance five other ballast configurations
  • Core and coil ballast with dry film capacitor
