WHITE RODGERS 16E09-101 24-240VAC ELEC TEMP CONTROL
MFR Part #: 16E09-101
SKU #: 1115983
Brand: White-Rodgers™
UPC: 786710530593
White-Rodgers™ 16E09-101 Electronic Temperature Control, -40 to 220 deg F Control, SPDT Switch, 24/120/208/240 V AC, Import
UL 94VO
Product Details
Attributes
Features
Resources
White-Rodgers™ Electronic Temperature Control, -40 to 220 deg F Control Range, SPDT, 24/120/208/240 V AC, 16 to 8 A, Gray, 6-3/4 in H x 3 in W x 2-9/16 in D, Import
Amperage Rating:16 to 8 A
Control Range:-40 to 220 deg F
Country Of Origin:China
Dimensions:6-3/4 in H x 3 in W x 2-9/16 in D
Domestic/Import:Import
Finish:Gray
Switch Action:SPDT
Voltage Rating:24/120/208/240 V AC
- Superior temperature control and accuracy for both refrigeration and heating application
- 24/120/208/240 volts multiple inputs
- No common wires required (electrical loads must be greater than 2.5 amp and uninterrupted)
- Electronic temperature accuracy/digital display
- Alarm outputs (with selectable delay - up to 99 minutes)
- Adjustable anti short cycle delay
- Set points locking function
- Reduces inventory, replaces most competitive mechanical and electronic refrigeration control
- Multiple sensor options can be used with 1 or 4 sensor
- 1 hp of horse power
- 1 to 30 deg of differentials temperature
- Full loads amp 16 A/120 VAC, 9.2 A/208 VAC, 8 A/240 VAC
- 96 A/120 VAC, 55.2 A/208 VAC,48 A/240 VAC of locked rotor amp
- 16 A/120 VAC, 16 A/208 VAC,16 A/240 VAC of non-inductive amp
- 96 A/120 VAC, 55.2 A/208 VAC, 48 A/240 VAC of locked rotor amp
- -40 to 220 deg F set point ranges
- 0 to 95 percent relative humidity
- 85 deg F maximum deg points
- -29 to 140 deg F of operating temperature
- -40 to 185 deg F of storage temperature
Product Details
White-Rodgers™ Electronic Temperature Control, -40 to 220 deg F Control Range, SPDT, 24/120/208/240 V AC, 16 to 8 A, Gray, 6-3/4 in H x 3 in W x 2-9/16 in D, Import
Attributes
Amperage Rating: 16 to 8 A
Control Range: -40 to 220 deg F
Country Of Origin: China
Dimensions: 6-3/4 in H x 3 in W x 2-9/16 in D
Domestic/Import: Import
Finish: Gray
Switch Action: SPDT
Voltage Rating: 24/120/208/240 V AC
Features
- Superior temperature control and accuracy for both refrigeration and heating application
- 24/120/208/240 volts multiple inputs
- No common wires required (electrical loads must be greater than 2.5 amp and uninterrupted)
- Electronic temperature accuracy/digital display
- Alarm outputs (with selectable delay - up to 99 minutes)
- Adjustable anti short cycle delay
- Set points locking function
- Reduces inventory, replaces most competitive mechanical and electronic refrigeration control
- Multiple sensor options can be used with 1 or 4 sensor
- 1 hp of horse power
- 1 to 30 deg of differentials temperature
- Full loads amp 16 A/120 VAC, 9.2 A/208 VAC, 8 A/240 VAC
- 96 A/120 VAC, 55.2 A/208 VAC,48 A/240 VAC of locked rotor amp
- 16 A/120 VAC, 16 A/208 VAC,16 A/240 VAC of non-inductive amp
- 96 A/120 VAC, 55.2 A/208 VAC, 48 A/240 VAC of locked rotor amp
- -40 to 220 deg F set point ranges
- 0 to 95 percent relative humidity
- 85 deg F maximum deg points
- -29 to 140 deg F of operating temperature
- -40 to 185 deg F of storage temperature
