LEVITON ZLD1Z-I0W 120/277V 1-POLE FIXTURE INTEGRATED OCCUPENCY SENSOR WITH BLUETOOTH & 2 INTERCHANGEABLE LENSES
MFR Part #: ZLD1Z-I0W
SKU #: 1268885
Brand: Leviton®
UPC: 7847721412
Leviton® ZLD1Z-I0W Smart Sensor, 120 to 277 V AC, Occupancy/Vacancy Sensor, 360 deg Viewing
5 Years
For Warehouses, Loading bays, Outdoor Lighting, Parking garages, Gymnasiums, Libraries, High-bay, Wet Location
IECC|ASHRAE 90.1|2019 Title 24, Part 6|IP66|ASHRAE 90.1
Product Details
Attributes
Features
Resources
Leviton®, ZLD1Z-I0W, Sensor, Smart, 120 to 277 V AC, Occupancy/Vacancy Sensor, 360 deg Viewing, 50, 60 Hz Response, IP66 Enclosure, -40 to 75 deg C, White, 3.75 in L x 1.39 in W x 0.97 in D Dimensions
Color:White
Dimensions:3.75 in L x 1.39 in W x 0.97 in D
Enclosure Type:IP66
Response Frequency:50, 60 Hz
Sensor Type:Occupancy/Vacancy
Temperature Rating:-40 to 75 deg C
Type:Smart
Viewing Angle:360 deg
Voltage Rating:120 to 277 V AC
- 120-277V Models 120-277VAC 1-pole
- Universal voltage models120-347VAC 1-pole 208-480VAC 2-pole
- Mesh grouping16 devices per group Occupancy Daylighting
- Scheduling - Universal voltage models only Weekly scheduling Time clock or astronomical clock Change level, operating mode, daylight mode Models without the integral scheduling feature can be part of a group with scheduling Controls LED lighting loads up to 6.7A
- Single-level switching
- Occupancy mode, Disabled (Photocell only) Auto-ON/Auto-OFF
- 360 deg field-of-view provides up to 8,250 square feet of coverage 8-20 ft and 20-40 ft lenses plus aisle way masks included
- Commissioning - App Enabled
- Mounting - Integrated into Light Fixture
- Product Line - Smart Sensors
- Sensor Technology - Passive Infrared (PIR)
Product Details
Leviton®, ZLD1Z-I0W, Sensor, Smart, 120 to 277 V AC, Occupancy/Vacancy Sensor, 360 deg Viewing, 50, 60 Hz Response, IP66 Enclosure, -40 to 75 deg C, White, 3.75 in L x 1.39 in W x 0.97 in D Dimensions
Attributes
Color: White
Dimensions: 3.75 in L x 1.39 in W x 0.97 in D
Enclosure Type: IP66
Response Frequency: 50, 60 Hz
Sensor Type: Occupancy/Vacancy
Temperature Rating: -40 to 75 deg C
Type: Smart
Viewing Angle: 360 deg
Voltage Rating: 120 to 277 V AC
Features
- 120-277V Models 120-277VAC 1-pole
- Universal voltage models120-347VAC 1-pole 208-480VAC 2-pole
- Mesh grouping16 devices per group Occupancy Daylighting
- Scheduling - Universal voltage models only Weekly scheduling Time clock or astronomical clock Change level, operating mode, daylight mode Models without the integral scheduling feature can be part of a group with scheduling Controls LED lighting loads up to 6.7A
- Single-level switching
- Occupancy mode, Disabled (Photocell only) Auto-ON/Auto-OFF
- 360 deg field-of-view provides up to 8,250 square feet of coverage 8-20 ft and 20-40 ft lenses plus aisle way masks included
- Commissioning - App Enabled
- Mounting - Integrated into Light Fixture
- Product Line - Smart Sensors
- Sensor Technology - Passive Infrared (PIR)
