WEIL MCLAIN 383700153 Image 1

WEIL MCLAIN 383-700-153 WM97PLUS 110 BOILER CIRC

MFR Part #: 383700153
SKU #: 1160696
Brand: Weil-McLain®
UPC: 672619192102
Weil-McLain® 383700153 Circulator Pump, 18 gpm, 115 V, 60 Hz, 125 psi Max Pressure, 3250 rpm Motor
For the wide range of flow and head requirements of today's hydronic heating systems
cULus Listed

Weil-McLain® Circulator Pump, 18 gpm Flow Rate, 17 ft Maximum Head, 115 V, 60 Hz, 125 psi Maximum Pressure, 3250 rpm Motor Speed Rating, 1/20 hp, 3/4 in, 1 in, 1-1/4 in, 1-1/2 in Connection, Flanged Connection, 1 ph Phase, 230 deg F Fluid

Product Details

Weil-McLain® Circulator Pump, 18 gpm Flow Rate, 17 ft Maximum Head, 115 V, 60 Hz, 125 psi Maximum Pressure, 3250 rpm Motor Speed Rating, 1/20 hp, 3/4 in, 1 in, 1-1/4 in, 1-1/2 in Connection, Flanged Connection, 1 ph Phase, 230 deg F Fluid

Attributes

Connection Type: Flanged
Flow Rate: 18 gpm
Frequency Rating: 60 Hz
Phase: 1 ph
Pressure Rating: 125 psi Working
Temperature Rating: 230 deg F Fluid
Voltage Rating: 115 V
Connection Size: 3/4 in, 1 in, 1-1/4 in, 1-1/2 in
HP Rating: 1/20 hp
Maximum Head: 17 ft
Maximum Pressure: 125 psi
Motor Speed Rating: 3250 rpm
Speed Rating: 3250 rpm

Features

  • Three speed switch
  • Fine tune to system requirements
  • Highest performance and starting torque in class
  • Heavy-duty construction for longer life
  • Replaceable cartridge design
  • Quiet, efficient operation
  • Self lubricating, no mechanical seal
