COMMANDER QBH-260 2 POLE 60 AMP BREAKER
MFR Part #: QBH260
SKU #: 0710140
Brand: Cutler-Hammer
UPC: 400000514079
Cutler-Hammer QBH260 Type QBH Classic Replacement Circuit Breaker, 120/240 VAC, 60 A, 10 kA Interrupt, 2 Poles, Thermal/Magnetic Trip
Loadcentres, Lighting/Distribution Panelboards and Meter Centres
UL Listed | CSA Certified
Product Details
Attributes
Features
Resources
Cutler-Hammer Classic Replacement Circuit Breaker, Type QBH, 120/240 VAC, 60 A, 10 kA Interrupt, Thermal/Magnetic Trip, 2 Pole, 1 ph ph, Handle Actuator, Bolt-On Connection, 10 to 2 AWG Wire, 60 to 75 deg C
Amperage Rating:
60 A
Number of Poles:
2
Actuator Type:
Handle
Connection Type:
Bolt-On
Interrupt Rating:
10 kA
Phase:
1
Temperature Rating:
60 to 75 deg C
Trip Type:
Thermal/Magnetic
Type:
Type QBH
Voltage Rating:
120/240 VAC
Wire Size:
10 to 2 AWG
- 3/4 in form factor
- Designed to fit the classic CEB, Sylvania or Commander electric design bolt-on loadcentres
- Silver tungsten contacts with wiping action to prevent carbon buildup on the contact surface
- Handle provides clear indication of ON/OFF/TRIPPED position
- Quick-make/quick-break mechanism provides tease-proof operation
- Internal common trip mechanism on two-pole circuit breakers
- Each breaker is electronically calibrated for 40 deg C
- Compression molded housing and handle for durability and service
- Residential and light commercial distribution
Product Details
Cutler-Hammer Classic Replacement Circuit Breaker, Type QBH, 120/240 VAC, 60 A, 10 kA Interrupt, Thermal/Magnetic Trip, 2 Pole, 1 ph ph, Handle Actuator, Bolt-On Connection, 10 to 2 AWG Wire, 60 to 75 deg C
Attributes
Amperage Rating: 60 A
Number of Poles: 2
Actuator Type: Handle
Connection Type: Bolt-On
Interrupt Rating: 10 kA
Phase: 1
Temperature Rating: 60 to 75 deg C
Trip Type: Thermal/Magnetic
Type: Type QBH
Voltage Rating: 120/240 VAC
Wire Size: 10 to 2 AWG
Features
- 3/4 in form factor
- Designed to fit the classic CEB, Sylvania or Commander electric design bolt-on loadcentres
- Silver tungsten contacts with wiping action to prevent carbon buildup on the contact surface
- Handle provides clear indication of ON/OFF/TRIPPED position
- Quick-make/quick-break mechanism provides tease-proof operation
- Internal common trip mechanism on two-pole circuit breakers
- Each breaker is electronically calibrated for 40 deg C
- Compression molded housing and handle for durability and service
- Residential and light commercial distribution
