JUNO T308 WH Image 1

WHITE MINI UNIVERSAL JUNO T308WH

MFR Part #: T308 WH
SKU #: 0691825
Brand: Acuity Brands | Juno®
UPC: 661209006899
Juno® Trac-Master® T308 WH Line Voltage Track Head, Incandescent Lamp, 120 V AC, Universal Head, 4 in Maximum Extension
This product may be subject to ecological fees.
On/Off Switch
Trac Lighting Applications
UL Listed | CSA Certified

Juno® Trac-Master™ Track Head, Line Voltage, Series: T308, Incandescent Lamp, 120 V AC, 150 W Lamp, 4 in Maximum Extension, Medium Lamp Base, 1 Lamps, Universal Head, 7-1/4 in Length, Steel Housing, White Housing

The economical Juno® Trac-Master™ T308 series universal is a basic line voltage trac fixture that accepts a wide range of popular PAR halogen and B/BR incandescent lamps.

Product Details

Juno® Trac-Master™ Track Head, Line Voltage, Series: T308, Incandescent Lamp, 120 V AC, 150 W Lamp, 4 in Maximum Extension, Medium Lamp Base, 1 Lamps, Universal Head, 7-1/4 in Length, Steel Housing, White Housing

The economical Juno® Trac-Master™ T308 series universal is a basic line voltage trac fixture that accepts a wide range of popular PAR halogen and B/BR incandescent lamps.

Attributes

Number of Lamps1
Diameter3-1/2 in
Housing FinishWhite
Housing MaterialSteel
Lamp TypeIncandescent
Lamp Wattage150 W
Length7-1/4 in
Maximum Extension4 in
Mounting TypeFixture
SeriesT308
TypeLine Voltage
Voltage Rating120 V AC

Features

  • Drawn steel housing with steel yoke
  • 90 deg C vertical aiming capability and 358 deg C rotation, 1-locking knob provided
  • Medium base porcelain socket with nickel plated copper screw shell, socket is adjustable for proper lamp positioning
  • Trac adapter features copper alloy contacts that provide precise spring action
  • No arcing and will not take a set
  • True, positive electrical ground
  • Spring loaded locking latch with embossed polarity arrows secures trac light to trac
  • Pull-up contact to up position for 2-circuit application
  • Polarity indicator embossed on bottom of adapter
  • For use with 27 to 50 W R20/35 to 50 W PAR20/45 to 85W BR30/35 to 75 W PAR30/65 to 120 W BR40/45 to 150 W PAR38 lamps
