TECHSPAN BCU1/0 SH COPPER SPLICE 1/0STR 3/8 PNK

MFR Part #: BCU-1/0
SKU #: 1133757
Brand: Techspan® | Penn-Union™
UPC: 77685614025
Penn-Union™ by Techspan® BCU-1/0 BCU Standard Barrel Compression Splice, 1/0 AWG Concentric/Compressed/Compact Copper Stranding Conductor, Die Code: B-12, 1.88 in L, Copper
CE Marked | CSA Certified | RoHS Compliant | UL Listed

Penn-Union™ by Techspan® Compression Splice, Standard Barrel, Series: BCU, Concentric/Compressed/Compact Copper Stranding Conductor, 1/0 AWG Conductor, Die Code: B-12, 1.88 in Length, Crimp Connector, 35 kV, 0.88 in L Insertion, 1 in L Wire Strip, Copper, Tin Plated, Pink, 3/8 in Dia

Product Details

Penn-Union™ by Techspan® Compression Splice, Standard Barrel, Series: BCU, Concentric/Compressed/Compact Copper Stranding Conductor, 1/0 AWG Conductor, Die Code: B-12, 1.88 in Length, Crimp Connector, 35 kV, 0.88 in L Insertion, 1 in L Wire Strip, Copper, Tin Plated, Pink, 3/8 in Dia

Attributes

Color: Pink
Conductor Size: 1/0 AWG
Connector Type: Crimp
Dimensions: 3/8 in Dia
Finish: Tin Plated
Length: 1.88 in
Material: Copper
Rewards: AD Rewards
Voltage Rating: 35 kV

Features

  • Manufactured from high conductivity seamless copper tubing
  • TiN plated to inhibit corrosion
  • Beveled entry for easy cable insertion
  • Positive cable stops to ensure proper insertion of conductors to full depth
  • Color coded barrels are marked with die index numbers
  • Connectors are suitable for voltages up to 35 kV if taped according to accepted practices, 5 kV is the maximum voltage level in all bare splice applications

Resources

Specification Sheet
