DYSON 307174-01 Image 1

DYSON 307174-01 HU02 AIRBLADE V QUIET LOW VOLTAGE - NICKEL

MFR Part #: 307174-01
SKU #: 1165911
Brand: dyson
UPC: 885609009933
dyson 307174-01 Hand Dryer, Automatic, 30 s Auto Cut-Off, Polycarbonate, Back Plate, Surface Mounting
5 Year Parts and Labor
For bathrooms
ADA Approved | Carbon Trust Certified | LEED Certified | NSF Certified | Quiet Marked | UL Listed

dyson Hand Dryer, 110 to 120 V, 15 A, 1000 W, 50/60 Hz, 12 s Dry Time, 420 mph Air Flow Velocity, Up to 42.38 cfm Air Flow Capacity, Automatic, 30 s Auto Cut-Off Time, 79 dB Sound Level, IP24 Enclosure, Back Plate, Surface Mounting, Polycarbonate, Finish: Sprayed Nickel, 9-1/4 in Width, 15-1/2 in Height, 4 in Depth, 32 to 104 deg F

Product Details

dyson Hand Dryer, 110 to 120 V, 15 A, 1000 W, 50/60 Hz, 12 s Dry Time, 420 mph Air Flow Velocity, Up to 42.38 cfm Air Flow Capacity, Automatic, 30 s Auto Cut-Off Time, 79 dB Sound Level, IP24 Enclosure, Back Plate, Surface Mounting, Polycarbonate, Finish: Sprayed Nickel, 9-1/4 in Width, 15-1/2 in Height, 4 in Depth, 32 to 104 deg F

Attributes

Air Flow Capacity: Up to 42.38 cfm
Air Flow Velocity: 420 mph
Amperage Rating: 15 A
Auto Cut-Off Time: 30 s
Automatic/Manual: Automatic
Depth: 4 in
Dry Time: 12 s
Enclosure Type: IP24
Finish: Sprayed Nickel
Frequency Rating: 50/60 Hz
Height: 15-1/2 in
Material: Polycarbonate
Mounting Type: Back Plate, Surface
Power Rating: 1000 W
Sound Level: 79 dB
Temperature Rating: 32 to 104 deg F
Voltage Rating: 110 to 120 V
Width: 9-1/4 in

Resources

Specification Sheet
