3M 7000133561 1/2IN X 4FT CLR HEAT SHRINK FP301H-1/2X48CL

MFR Part #: 7000133561
SKU #: 1020032
Brand: 3M™
UPC: 00051128596692
3M™ 7000133561 FP-301 Thin Wall Heat Shrink Tube, 1/2 in ID Expanded, 1/4 in ID Recovered, 0.025 in THK Wall Recovered, 48 in L, Polyolefin, Clear
Lightweight Wire Harness Covering, Fire-Resistant Covering, Wire Marking, Wire Bundling and Component Packaging Applications
RoHS Compliant | ABS Certified | UL Listed | CSA Certified | SAE-AMS-DTL-23053/5/AMS-3636/3637 | UL Recognized | SAE AS23053/5 Class I

3M™, 7000133561, Heat Shrink Tube, Thin Wall, Series: FP-301, 600 VAC, 1/2 in ID Expanded, 1/4 in ID Recovered, Thin Wall, 0.025 in Wall Thickness Recovered, 2:1 Shrink Ratio, 48 in Length, 67 to 275 deg F, 212 deg F Shrink, Polyolefin, Clear

3M™ heat shrink tubing fp-301 is color coded for quick and easy identification of the wire. This split-resistant, flame-retardant tubing is used as shrink fit, electrical insulation over cable splices or terminations. The high expansion ratio tubing is mechanically tough, easily markable and resists cold flow. It is ideal for lightweight wire-harness covering, fire-resistant covering, wire marking, wire bundling and component packaging.

Product Details

3M™, 7000133561, Heat Shrink Tube, Thin Wall, Series: FP-301, 600 VAC, 1/2 in ID Expanded, 1/4 in ID Recovered, Thin Wall, 0.025 in Wall Thickness Recovered, 2:1 Shrink Ratio, 48 in Length, 67 to 275 deg F, 212 deg F Shrink, Polyolefin, Clear

3M™ heat shrink tubing fp-301 is color coded for quick and easy identification of the wire. This split-resistant, flame-retardant tubing is used as shrink fit, electrical insulation over cable splices or terminations. The high expansion ratio tubing is mechanically tough, easily markable and resists cold flow. It is ideal for lightweight wire-harness covering, fire-resistant covering, wire marking, wire bundling and component packaging.

Attributes

Color: Clear
Country Of Origin: US
Dielectric Strength: 900 V/mil
Heat Shock: No Dripping
Inner Diameter Expanded: 1/2 in
Inner Diameter Recovered: 1/4 in
Inside Diameter Expanded: 1/2 in
Inside Diameter Recovered: 1/4 in
Length: 48 in
Low Temperature Flexibility: No Cracking
Material: Polyolefin
Recovered Wall Thickness: .025 in
Secant Modulus: 13000 psi
Series: FP-301 Series, FP-301
Shrink Ratio: 2:1, 02:01:00
Shrink Temperature: 212 deg F
Temperature Rating: 67 to 275 deg F, -67 to 275 deg F
Tensile Strength: 2400 psi
Type: Corrosion-Resistant Flame-Retardant Flexible General Purpose
Ultimate Elongation: 400 %
Voltage Rating: 600 V, 600 VAC
Wall Thickness Recovered: .025 in
Wall Type: Thin
Water Absorption: .2 %

Features

  • Used as a shrink-fit electrical insulation over cable splices and terminations
  • 10 years shelf life from date of manufacture
  • Low temperature flexibility, no cracking
  • No dripping, flowing, cracking heat shock
  • 10^15 Ohm-cm volume resistivity
  • 900 V/mil dielectric strength
  • 0.2% water absorption
  • 2400 psi tensile strength
  • 175% elongation for 336 hr at 175 deg c heat aging
  • 1.3 specific gravity
  • +/-5% longitudinal change
  • Offers shrink-fit protection and strain relief of wires, solder joints, terminals and connections
  • HIGH-STRENGTH PROTECTION, Balances electrical, physical, and chemical properties for various industrial and military applications
