CUTLER HAMMER BAB3100H Image 1
CUTLER HAMMER BAB3100H Image 2
CUTLER HAMMER BAB3100H Image 3
CUTLER HAMMER BAB3100H Image 4
content loaded
CUTLER HAMMER BAB3100H Image 1

CUTLER HAMMER BAB3100H 3 POLE 100 AMP BOLT-IN BREAKER

MFR Part #: BAB3100H
SKU #: 0711475
Brand: EATON
UPC: 786679304006
EATON QuickLag® BAB3100H Type BAB Miniature Circuit Breaker, 240 VAC, 100 A, 10 kA Interrupt, 3 Poles, Non-Interchangeable Trip
Datacentres, IT Space, CI and Hyper Converged, Generation - Conventional Energy, Renewable Energy, Alternative Energy, Marine Vessels and Equipment, Residential Buildings and Facilities, Circuit Protection and Industrial Applications
CSA Certified | HACR Rated | UL 489

EATON QuickLag® Miniature Circuit Breaker, Type BAB, 240 VAC, 100 A, 10 kA Interrupt, Non-Interchangeable Trip, 3 Pole, Extended Tang Line/Box Lug Load, 14 to 4 AWG Wire, Bolt-On Mount, 40 deg C, 2.9 x 3 x 2.9 in

Eaton’s bolt-on miniature circuit breakers (Quicklag) provide superior protection in panelboards, and offer easy installation. They are also switching duty rated for 120 VAC fluorescent light applications, and UL 489 listed. All products 15–100A are HACR rated. Select from one-, two-, or three-pole designs.

Product Details

EATON QuickLag® Miniature Circuit Breaker, Type BAB, 240 VAC, 100 A, 10 kA Interrupt, Non-Interchangeable Trip, 3 Pole, Extended Tang Line/Box Lug Load, 14 to 4 AWG Wire, Bolt-On Mount, 40 deg C, 2.9 x 3 x 2.9 in

Eaton’s bolt-on miniature circuit breakers (Quicklag) provide superior protection in panelboards, and offer easy installation. They are also switching duty rated for 120 VAC fluorescent light applications, and UL 489 listed. All products 15–100A are HACR rated. Select from one-, two-, or three-pole designs.

Attributes

Amperage Rating: 100 A
Country Of Origin: Dominican Republic
Number of Poles: 3
Connection Type: Bolt-On, Extended Tang Line/Box Lug Load
Dimensions: 2.9 x 3 x 2.9 in
Frame Type: BAB
Height: 2.9 in
Interrupt Rating: 10 kA
Length: 2.9 in
Mounting Type: Bolt-On
Phase: 3 ph
Temperature Rating: 40 deg C
Terminal Type: Extended Tang Line
Trip Type: Non-Interchangeable, Thermal Magnetic, Non-Interchangeable
Type: Type BAB
Voltage Rating: 240 VAC
Width: 3 in
Wire Size: 8 to 1/0 AWG, 14 to 4 AWG

Features

  • Flexible power feed connection
  • Field mountable accessories make installations and on-site custom configuration easy

Resources

Owners/User Manual
Specification Sheet
