ABB 1SVR405622R2100 CR-U120AC3L PLUGGABLE RELAY
MFR Part #: 1SVR405622R2100
SKU #: 1287604
Brand: ABB
UPC: 662019354682
ABB 1SVR405622R2100 CR General Purpose Pluggable Universal Interface Relay With LED Indicator, 5 mA, 3CO 3 Form C 3PDT Contact, 120 VAC V Coil
For applications where low current control voltage is used to switch higher current or voltage loads
RoHS Compliant|UL Listed|CE Certified|CSA Certified|CE Certified|CSA Certified|GOST|RoHS Compliant
Product Details
Attributes
Features
Resources
ABB, 1SVR405622R2100, Universal Interface Relay With LED Indicator, General Purpose Pluggable, Series: CR, 5 mA, 0.3 W Power, 50/60 Hz Frequency, 120 VAC Coil, 3CO 3 Form C 3PDT Contact Form, 10 A at 250 VAC Contact, Socket Mounting, IP40 Enclosure, -40 to 55 deg C, 54.4 mm H x 35 mm W x 35 mm D Dimensions
Amperage Rating:5 mA
Coil Voltage:120 VAC
Contact Form:3CO 3 Form C 3PDT
Contact Rating:10 A at 250 VAC
Dimensions:54.4 mm H x 35 mm W x 35 mm D
Enclosure Type:IP40
Frequency Rating:50/60 Hz
Mounting Type:Socket
Power Rating:.3 W
Series:CR
Temperature Rating:-40 to 55 deg C
Type:General Purpose Pluggable
- Standard miniature relays with mechanical status indication
- The relay has an integrated blue test button for manual actuation and locking of the output contacts
- Suited for logical and standard sockets
- Cadmium free contact
- Pluggable function modules - reverse polarity protection/free wheeling diode, LED indication, RC elements, overvoltage protection, time modules
Product Details
ABB, 1SVR405622R2100, Universal Interface Relay With LED Indicator, General Purpose Pluggable, Series: CR, 5 mA, 0.3 W Power, 50/60 Hz Frequency, 120 VAC Coil, 3CO 3 Form C 3PDT Contact Form, 10 A at 250 VAC Contact, Socket Mounting, IP40 Enclosure, -40 to 55 deg C, 54.4 mm H x 35 mm W x 35 mm D Dimensions
Attributes
Amperage Rating: 5 mA
Coil Voltage: 120 VAC
Contact Form: 3CO 3 Form C 3PDT
Contact Rating: 10 A at 250 VAC
Dimensions: 54.4 mm H x 35 mm W x 35 mm D
Enclosure Type: IP40
Frequency Rating: 50/60 Hz
Mounting Type: Socket
Power Rating: .3 W
Series: CR
Temperature Rating: -40 to 55 deg C
Type: General Purpose Pluggable
Features
- Standard miniature relays with mechanical status indication
- The relay has an integrated blue test button for manual actuation and locking of the output contacts
- Suited for logical and standard sockets
- Cadmium free contact
- Pluggable function modules - reverse polarity protection/free wheeling diode, LED indication, RC elements, overvoltage protection, time modules
