ABB EOT32U3P3-S Image 1

ABB EOT32U3P3-S ENCLOSED SWITCHES 40A/3P/600VAC

MFR Part #: EOT32U3P3-S
SKU #: 1057951
Brand: ABB
UPC: 662019444895
ABB EOT32U3P3-S EOT Non-Fused Enclosed Disconnect Switch, 600 VAC, 40 A, 10 hp at 220 to 240 VAC, 20 hp at 480 VAC, 25 hp at 600 VAC, 3 Poles
For industrial control panel disconnects
UL 508 | IEC 60529 | UL 508 | UL 98 | cUL Listed | CSA C22.2 No. 14

ABB, EOT32U3P3-S, Enclosed Disconnect Switch, Non-Fused, Series: EOT, 600 VAC, 40 A, 10 hp at 220 to 240 VAC, 20 hp at 480 VAC, 25 hp at 600 VAC, 3 Pole, Selector Handle Actuator, NEMA 3R/12/IP65 Enclosure, Surface Mounting, Screw Terminal, 60 to 75 deg C, 161.4 mm H x 100 mm W x 81 mm D Dimensions, Plastic

The eOT series of enclosed manual motor controllers are rotary operated, 3 and 4-pole, 600V hp rated switches, housed in thermoplastic/polycarbonate, sheet steel or stainless steel enclosures. They are suitable for wet and corrosive environments.

Product Details

ABB, EOT32U3P3-S, Enclosed Disconnect Switch, Non-Fused, Series: EOT, 600 VAC, 40 A, 10 hp at 220 to 240 VAC, 20 hp at 480 VAC, 25 hp at 600 VAC, 3 Pole, Selector Handle Actuator, NEMA 3R/12/IP65 Enclosure, Surface Mounting, Screw Terminal, 60 to 75 deg C, 161.4 mm H x 100 mm W x 81 mm D Dimensions, Plastic

The eOT series of enclosed manual motor controllers are rotary operated, 3 and 4-pole, 600V hp rated switches, housed in thermoplastic/polycarbonate, sheet steel or stainless steel enclosures. They are suitable for wet and corrosive environments.

Attributes

Amperage Rating: 40 A
Enclosure Type: NEMA 3R/12/IP65
Actuator Type: Selector Handle
Dimensions: 161.4 mm H x 100 mm W x 81 mm D
Horsepower: 10 hp at 220 to 240 VAC, 20 hp at 480 VAC, 25 hp at 600 VAC
Material: Plastic
Mounting Type: Surface
Number of Poles: 3
Series: EOT
Temperature Rating: 60 to 75 deg C
Terminal Type: Screw
Type: Non-Fused
Voltage Rating: 600 VAC

Features

  • Quick make, quick brake mechanism
  • Fingerproof construction
  • Positive operation
  • Plastic enclosure installs flush on mounting surface, reducing the accumulation of dirt behind the enclosure
  • Clear position indication
  • Suitable as motor disconnect
  • No hazardous exposed parts
  • Touch safe construction
  • Horsepower rated
  • Extremely compact size
  • Self lifting tunnel terminals
