ACTUATING MOTOR TEKMAR 741
Product Details
Attributes
Features
Resources
Tekmar® Actuating Motor, Floating Action, Actuating Motor Accessory Type, 24 V AC +/-10%, 60 Hz, 1.5VA Power Supply, 3 in W x 3-1/2 in D x 3-1/2 in H, Import
The Actuating Motor 741 is a 24 V floating action actuator designed to operate all Tekmar brass mixing valves (710 to 724). It receives a 24 V open or close signal, which causes the motor to open or close the valve. It provides 6 Nm (53 in lbs) of torque over a 90 deg rotation. This product rotates its output shaft whenever 24 VAC is applied between either the counter clockwise or clockwise terminals and the Com terminal. It is compatible with any control having a 24 VAC floating output.
- Electrically limited to 90 deg shaft rotation
- 105 s open or close time at 60 Hz
Product Details
Tekmar® Actuating Motor, Floating Action, Actuating Motor Accessory Type, 24 V AC +/-10%, 60 Hz, 1.5VA Power Supply, 3 in W x 3-1/2 in D x 3-1/2 in H, Import
The Actuating Motor 741 is a 24 V floating action actuator designed to operate all Tekmar brass mixing valves (710 to 724). It receives a 24 V open or close signal, which causes the motor to open or close the valve. It provides 6 Nm (53 in lbs) of torque over a 90 deg rotation. This product rotates its output shaft whenever 24 VAC is applied between either the counter clockwise or clockwise terminals and the Com terminal. It is compatible with any control having a 24 VAC floating output.
Attributes
Features
- Electrically limited to 90 deg shaft rotation
- 105 s open or close time at 60 Hz
